Bike Build Specs
CALL 860-537-4306 or E-mail techinfo@avalanchedownhillracing.com us for more details and help
LET AVALANCHE SUSPENSION HELP CREATE YOUR BUILD
All data is our best estimate based on the information provided online
2019 KNOLLY Delirium
| MODEL VERSION YEARS | |
|---|---|
| TIRE SIZE | 27.5 |
| FRAME MATERIAL | ALLOY (alum) |
| BIKE WEIGHT (lbs) | 33 |
| SHOCK SIZE | 8.75 x 2.75 |
| TRAVEL MM | 170 |
| UPPER REDUCER | 21.8 x 8.0 |
| LOWER REDUCER | 33.0 x 8.0 |
| LINKAGE | FOUR x FOUR BAR (PROGRESSIVE) |
| AVERAGE LEVERAGE | 2.43 |
| STARTING LEVERAGE | 3.35 |
| SAG POINT LEVERAGE | 2.9 |
| ENDING LEVERAGE | 2.35 |
| PROGRESSION % | 29.9 |
| LEVERAGE CURVE | PBLE
|
| Installed Pictures | Installed Views |
| SHOCK TUNE | PROGRESSIVE PBLE |
| OEM SHOCK | FOX FLOAT X2 |
| UPGRADE OPTION | BOMBER CR |
| UPGRADE OPTION | FOX DHX |
| SUGGESTED SHOCK SPRING | 300,350,400,400,450,500, |
| HEAD TUBE ANGLE | |
| RECOMMENDED FORK TRAVEL | 180 |
| OEM FORK | |
| UPGRADE OPTION CARTRIDGE/SPRING | ROCKSHOX ZEB HYBRID |
| UPGRADE OPTION CARTRIDGE/SPRING | Fox 38 HYBRID |
SUGGESTED FORK SPRING WITH OUR CARTRIDGE | 30,35,40,45,50,55, |
| COMMENTS | HAS OPTION FOR 8.5 X 2.5 |
| COMMENTS |
